PK2658 ~ 2-AXLE UNDERCARRIAGE 71" 60" FENDERS FOR ALUMINUM STEPS

REPRESENTATION PHOTO

MAGIC TILT UNDERCARRIAGE ~ PK2658

TYPE: TANDEM AXLE UNDERCARRIAGE FOR ALUMINUM STEPS
LENGTH: 71"
TRAILER SIDE: LEFT OR RIGHT
MOUNT LOCATION: OUTSIDE OF FRAME
STEP SIZE: 10" ALUMINUM STEP PADS (NOT INCLUDED)
MOST COMMON TIRE SIZE: 10" AND 13"
DISTANCE BETWEEN BRACKETS: 60"
SPRING SIZE: 20" DOUBLE EYE PJ1350 (NOT INCLUDED)
EQUALIZER: 6-1/2" PK1950 (NOT INCLUDED)
FENDERS: (NOT INCLUDED) PI1855 (DIAMOND TREAD) OR PI1857-S (SMOOTH)
MATERIAL: GALVANIZED

NOTES:
PRIMARILY USED ON ALUMINUM I-BEAM TRAILERS FOR PONTOON BOATS
HOLE SIZE FOR MOUNTING TO FRAME: 1/2" ON 4-1/4" CENTERS
BOLT PATTERN FOR MOUNTING TO FRAME MAY NOT MATCH EXISTING UNDERCARRIAGE
AXLE & SPRING-TO-UNDERCARRIAGE HARDWARE KITS:
   2x2 AXLES: GALVANIZED PK1150, STAINLESS/GALV PK1150-SS
   2x3 AXLES: GALVANIZED PK1152, STAINLESS/GALV PK1152-SS
SPRING EYE BOLT: PK1450
